Remotely operated underwater vehicle
SmartDive
SmartDive ROV is designed for inspection and search operations. With the help of the broadcast video, operator can find various objects under water, as well as inspect bridge supports, hydraulic structures, ship bottoms, fishing nets and much more.
SmartDive ROV Highlights
Compact
Small dimensions (465х377х265 mm) and low weight(13 kg) allow the ROV to move underwater even in narrow spaces and make the underwater vehicle conveniently portable on land.
Autonomous
Powerful battery provides the ROV with up to 4 hours of autonomous work (optionally up to 8 hours).
The ROV doesn't require any onshore power supply equipment, so it is truly autonomous. The operator's mobile workplace is also operated in an autonomous mode.
Powerful
The maximum working depth of the ROV is 150 meters, optionally up to 300 m.
SmartDive ROV has six brushless thrusters. Two of them are for vertical movement, and four are for horizontal.
The maximum forward speed is 1.5 m/s (optionally up to 1.8 m/s).
FullHD Camera with wide viewing angle
The ROV has a FullHD camera with a 105° viewing angle. It is located on a tilt mechanism with an ±80° vertical deflection angle. Additionally, we can install a 4K camera.
Powerful and Adjustable Light
Basic configuration of the SmartDive ROV includes 2 LED lights with a total luminous flux of 10,000 lumens. We can additionally install 2 more lights increasing the total luminous flux to 20,000 lumens. The glow angle of each light underwater is 95°.
Operator can control the lights remotely: turn them on, off and change the luminous flux power.
SmartDive ROV Specification
Feature/Value
SmartDive-100
SmartDive-150
SmartDive-150A
SmartDive-150AT
Feature/Value
Feature/Value
SmartDive-100
SmartDive-100
SmartDive-150
SmartDive-150
SmartDive-150A
SmartDive-150A
SmartDive-150AT
SmartDive-150AT
Maximum depth
100m
150m
150m
150m
Feature/Value
Maximum depth
SmartDive-100
100m
SmartDive-150
150m
SmartDive-150A
150m
SmartDive-150AT
150m
Maximum speed (forward movement)
1.5 m/s
1.5 m/s
1 m/s
1.5 m/s
Feature/Value
Maximum speed (forward movement)
SmartDive-100
1.5 m/s
SmartDive-150
1.5 m/s
SmartDive-150A
1 m/s
SmartDive-150AT
1.5 m/s
Dimensions
465х377х265 mm
465х377х265 mm
630х442х330 mm
650х450х340 mm
Feature/Value
Dimensions
SmartDive-100
465х377х265 mm
SmartDive-150
465х377х265 mm
SmartDive-150A
630х442х330 mm
SmartDive-150AT
650х450х340 mm
Weight on land
13 kg
13 kg
23 kg
34 kg
Feature/Value
Weight on land
SmartDive-100
13 kg
SmartDive-150
13 kg
SmartDive-150A
23 kg
SmartDive-150AT
34 kg
Brushless motors
6 pcs. (including 4 horizontal and 2 vertical)
6 pcs. (including 4 horizontal and 2 vertical)
6 pcs. (including 4 horizontal and 2 vertical)
6 pcs. (including 4 horizontal and 2 vertical)
Feature/Value
Brushless motors
SmartDive-100
6 pcs. (including 4 horizontal and 2 vertical)
SmartDive-150
6 pcs. (including 4 horizontal and 2 vertical)
SmartDive-150A
6 pcs. (including 4 horizontal and 2 vertical)
SmartDive-150AT
6 pcs. (including 4 horizontal and 2 vertical)
Thrust of each thruster, kgf
5
5
7,5
13
Feature/Value
Thrust of each thruster, kgf
SmartDive-100
5
SmartDive-150
5
SmartDive-150A
7,5
SmartDive-150AT
13
Electrical characteristics of motors
3-phase, direct current, rated voltage 16 V
3-phase, direct current, rated voltage 16 V
3-phase, direct current, rated voltage 24 V
3-phase, direct current, rated voltage 48 V
Feature/Value
Electrical characteristics of motors
SmartDive-100
3-phase, direct current, rated voltage 16 V
SmartDive-150
3-phase, direct current, rated voltage 16 V
SmartDive-150A
3-phase, direct current, rated voltage 24 V
SmartDive-150AT
3-phase, direct current, rated voltage 48 V
Adjustment of horizontal thruster direction
Three thruster positions: 1) For maximum forward speed 2) Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
Three thruster positions: 1) For maximum forward speed2) Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
Three thruster positions: 1) For maximum forward speed2)Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
Three thruster positions: 1) For maximum forward speed2)Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
Feature/Value
Adjustment of horizontal thruster direction
SmartDive-100
Three thruster positions: 1) For maximum forward speed 2) Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
SmartDive-150
Three thruster positions: 1) For maximum forward speed2) Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
SmartDive-150A
Three thruster positions: 1) For maximum forward speed2)Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
SmartDive-150AT
Three thruster positions: 1) For maximum forward speed2)Optimal position for both forward and lateral movement 3) For maximum lateral (sideways) speed
Battery life
up to 4 hours (optionally – up to 8 hours)
up to 4 hours (optionally – up to 8 hours)
up to 8 hours, depending on the working conditions
up to 4 hours, depending on the working conditions
Feature/Value
Battery life
SmartDive-100
up to 4 hours (optionally – up to 8 hours)
SmartDive-150
up to 4 hours (optionally – up to 8 hours)
SmartDive-150A
up to 8 hours, depending on the working conditions
SmartDive-150AT
up to 4 hours, depending on the working conditions
Battery (Li-ion)
18 A*h
18 A*h
36 A*h
18 A*h
Feature/Value
Battery (Li-ion)
SmartDive-100
18 A*h
SmartDive-150
18 A*h
SmartDive-150A
36 A*h
SmartDive-150AT
18 A*h
Battery charge time, h
2
2
3,5-4
2
Feature/Value
Battery charge time, h
SmartDive-100
2
SmartDive-150
2
SmartDive-150A
3,5-4
SmartDive-150AT
2
Operating temperature range (in water)
0...30°C
-5...45°C
-5...45°C
-5...45°C
Feature/Value
Operating temperature range (in water)
SmartDive-100
0...30°C
SmartDive-150
-5...45°C
SmartDive-150A
-5...45°C
SmartDive-150AT
-5...45°C
FullHD camera on a tilt mechanism
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
Feature/Value
FullHD camera on a tilt mechanism
SmartDive-100
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
SmartDive-150
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
SmartDive-150A
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
SmartDive-150AT
1080p, 30 fps, viewing angle: 105°, tilt range: ±80°
Light
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
Feature/Value
Light
SmartDive-100
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
SmartDive-150
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
SmartDive-150A
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
SmartDive-150AT
2 LED-lights of 5,000 lumens each (optionally – up to 4 lights). Beam angle: 95°
Light temperature
5000K
5000K
5000K
5000K
Feature/Value
Light temperature
SmartDive-100
5000K
SmartDive-150
5000K
SmartDive-150A
5000K
SmartDive-150AT
5000K
Lanterns can be controlled remotely
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
Feature/Value
Lanterns can be controlled remotely
SmartDive-100
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
SmartDive-150
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
SmartDive-150A
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
SmartDive-150AT
Turn on, turn off and change the luminous flux power. 2,500 lumens lights are available as an option
Adjustment of upper light direction
19° upward and 38° downward
19° upward and 38° downward
19° upward and 38° downward
19° upward and 38° downward
Feature/Value
Adjustment of upper light direction
SmartDive-100
19° upward and 38° downward
SmartDive-150
19° upward and 38° downward
SmartDive-150A
19° upward and 38° downward
SmartDive-150AT
19° upward and 38° downward
Adjustment of lower light direction
23° upward and downward, 30° to the right and left
23° upward and downward, 30° to the right and left
23° upward and downward, 30° to the right and left
23° upward and downward, 30° to the right and left
Feature/Value
Adjustment of lower light direction
SmartDive-100
23° upward and downward, 30° to the right and left
SmartDive-150
23° upward and downward, 30° to the right and left
SmartDive-150A
23° upward and downward, 30° to the right and left
SmartDive-150AT
23° upward and downward, 30° to the right and left
Case frame material
HDPE (low pressure polyethylene)
HDPE (low pressure polyethylene)
HDPE (low pressure polyethylene)
HDPE (low pressure polyethylene)
Feature/Value
Case frame material
SmartDive-100
HDPE (low pressure polyethylene)
SmartDive-150
HDPE (low pressure polyethylene)
SmartDive-150A
HDPE (low pressure polyethylene)
SmartDive-150AT
HDPE (low pressure polyethylene)
Kevlar fiber reinforced cable on a mechanical spool with sliding contact (electric spool optional)
Diameter: 7.25 mm. Length: 150 m (optionally – up to 300 m)
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
Feature/Value
Kevlar fiber reinforced cable on a mechanical spool with sliding contact (electric spool optional)
SmartDive-100
Diameter: 7.25 mm. Length: 150 m (optionally – up to 300 m)
SmartDive-150
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
SmartDive-150A
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
SmartDive-150AT
Diameter: 7.25 mm. Length: 300 m (optionally – up to 500 m)
Minimum breaking force of the cable
100 kgF
150 kgF
250 kgF
250 kgF
Feature/Value
Minimum breaking force of the cable
SmartDive-100
100 kgF
SmartDive-150
150 kgF
SmartDive-150A
250 kgF
SmartDive-150AT
250 kgF
Sensors on board
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
Feature/Value
Sensors on board
SmartDive-100
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
SmartDive-150
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
SmartDive-150A
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
SmartDive-150AT
Gyroscope, accelerometer, depth, seawater temperature, hull leaks (optional), compass, energy consumption control system
Mobile operator's workplace (optionally)
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
Feature/Value
Mobile operator's workplace (optionally)
SmartDive-100
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
SmartDive-150
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
SmartDive-150A
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
SmartDive-150AT
A portable computer with a bright screen in a shock-resistant, waterproof case. The SmartDive underwater drone control software is pre-installed on the computer. Wireless control joystick. Virtual reality headset (optional)
Warranty and service
12 months from the date of delivery
12 months from the date of delivery
12 months from the date of delivery
12 months from the date of delivery
Feature/Value
Warranty and service
SmartDive-100
12 months from the date of delivery
SmartDive-150
12 months from the date of delivery
SmartDive-150A
12 months from the date of delivery
SmartDive-150AT
12 months from the date of delivery
SmartDive ROV Video
SmartDive ROV Equipment
Basic equipment of SmartDive ROV
The basic set of the SmartDive ROV includes an underwater vehicle with a FullHD camera on a tilt mechanism, 2 LED-lights with a luminous flux of 10,000 lumens, a mechanical spool with a sliding contact, 150 meters of cable and control software.
To control the ROV you only need a laptop with an Ethernet connector and a joystick.
Mobile Operator's Workplace
The mobile operator's workplace includes a shockproof waterproof case, a laptop with a bright screen and a wireless joystick.
SmartDive ROV Custom Equipment
The SmartDive ROV is supplied in various configurations depending on the tasks of the customer.
Options with Additional Equipment
The ROV can be provided with additional equipment, such as 2 LED lights, manipulator arm, 4K camera, electric spool with sliding contact, up to 300 meters of cable, VR glasses, leak sensor and more.
Custom Manufacture of the ROV
Depending on the tasks of the customer, we can design and manufacture a customized version of the ROV with unique characteristics (working depth, battery life, etc.) and attachments (manipulator, 360° sonar, thickness gauge, laser pointers, UV lamps, etc.).
Learn more about the SmartDive ROV
Please read our Privacy Policy and Cookie Policy. The form can be sent only after you tick the consent box.
